薛松, 杨志兵, 陈益峰, 童富果. 交叉裂隙开度对滴状水流分流行为的影响[J]. 岩土工程学报, 2023, 45(1): 181-188. DOI: 10.11779/CJGE20211415
引用本文: 薛松, 杨志兵, 陈益峰, 童富果. 交叉裂隙开度对滴状水流分流行为的影响[J]. 岩土工程学报, 2023, 45(1): 181-188. DOI: 10.11779/CJGE20211415
XUE Song, YANG Zhibing, CHEN Yifeng, TONG Fuguo. Effects of fracture apertures on droplet splitting through unsaturated fracture intersections[J]. Chinese Journal of Geotechnical Engineering, 2023, 45(1): 181-188. DOI: 10.11779/CJGE20211415
Citation: XUE Song, YANG Zhibing, CHEN Yifeng, TONG Fuguo. Effects of fracture apertures on droplet splitting through unsaturated fracture intersections[J]. Chinese Journal of Geotechnical Engineering, 2023, 45(1): 181-188. DOI: 10.11779/CJGE20211415

交叉裂隙开度对滴状水流分流行为的影响

Effects of fracture apertures on droplet splitting through unsaturated fracture intersections

  • 摘要: 深入理解交叉裂隙渗流行为是预测裂隙网络渗流特性的关键。非饱和条件下交叉裂隙渗流与液体流态、交叉几何特征密切相关。针对低流量、低饱和度条件下的滴状渗流,开展了交叉裂隙液体分流模拟,发现了交叉处分流存在由液滴长度控制的主通道流动占优和支通道流动占优两种模式,并提出了关键液滴长度指标作为其临界条件。通过改变交叉裂隙主通道开度 w_1 和支通道开度 w_2 ,系统探究了交叉裂隙开度对分流模式的影响规律及机制。模拟结果表明关键液滴长度受到通道毛细力和通道过流能力的联合控制;当两者对分流作用效果相反时关键液滴长度随裂隙开度 w_1 呈非单调变化,而当两者作用效果一致时则随裂隙开度 w_1 呈单调变化。此外,存在一个相对稳定的最优开度比 w_2 / w_1 范围使关键液滴长度最大。研究成果为预测低流量、低饱和度条件下裂隙岩体渗流结构提供了理论和数据支撑。



    Abstract: An in-depth understanding of liquid flows through fracture intersections is important for predicting the seepage characteristics of fracture networks. The flow behavior of liquid at unsaturated intersections is closely related to the flow mode and geometric characteristics of fractures. A modeling study is given on the physical process of droplet splitting through unsaturated fracture intersections, which usually occurs under low flow rate and low saturation conditions. The effects of fracture apertures on droplet splitting behaviors are systematically investigated by varying the main channel width w1 and the branch width w2 of the fracture intersection. It is found that there are two droplet splitting patterns related to the droplet length: the flows dominated by the main channel and those dominated by the branch, which can be distinguished by the critical droplet length. This critical length is controlled by capillary force and permeability of channels, both varying with the channel widths. When the two controlling factors have opposite effects on the droplet splitting, the critical droplet length changes non-monotonously with w2. Conversely, the critical droplet length changes monotonously with w1. In addition, there is an optimal range for the width ratio w2/w1 to maximize the critical droplet length. This study provides theoretical support for predicting the seepage structure of fractured rocks under the conditions of low flow and low saturation.



/
