Several problems in refined local modeling for seismic response analysis of immersed tunnel
-
摘要: 通过大型沉管隧道的实例分析和前期研究成果,重点讨论沉管隧道地震反应分析中建立局部三维精细化模型时所应关注的4个问题:①模型范围大小的问题;②上覆水体动水作用的简化;③时域分析中阻尼矩阵的合理建模及其影响;④地震输入方式的选择与影响等。文中通过工程算例验证局部三维精细化建模的合理方式,研究结果表明:考察某段沉管管节的地震反应时,应至少考虑该管节两端各三段相邻管节的影响和轴向5倍以上土层厚度范围的土层影响;上覆水体可近似采用等效附加质量的方式模拟;当沉管隧道-土层体系的基频低于输入地震波的卓越频率时,易采用基于体系基频的优化方法来确定Rayleigh比例阻尼矩阵的比例系数;沿沉管隧道轴向的多点地震输入对隧道地震反应有较大影响,应加以充分关注。Abstract: Based on the case study of a large-scale immersed tunnel and the previous research results, several problems in establishing the refined local model for seismic response analysis of the immersed tunnel are discussed emphatically as follows: (1) problem of model range size, (2) simplified method for hydrodynamic action of overlying water body, (3) the proper model of damping matrix in time domain and its effect, (4) selection of seismic input mode and its effect. The reasonable way for three-dimensional refined local modeling of the immersed tunnel is verified by engineering examples. The numerical results show that when the seismic responses of an immersed tunnel pipe is investigated carefully, at least the influence of other three pipes at two sides of the pipe must be considered and the effect of the limited soil layer whose horizontal length is at least 5 times the thickness of the soil layer at two sides of the pipe should be included. The method of equivalent additional mass can be used to simulate the overlying water body. When the fundamental frequency of the immersed tunnel-soil layer system is lower than the predominate frequencies of the input seismic wave, the ratio coefficients of the Rayleigh proportional damping matrix are determined by the optimization method based on the fundamental frequency of the system. It should be fully noted that the excitation of multi-support seismic input along tunnel axis has a great influence on the seismic response of the immersed tunnel.
-
Keywords:
- immersed tunnel /
- seismic response analysis /
- local modeling /
- refinement calculation
-
[1] 陈 越. 港珠澳大桥岛隧工程建造技术综述[J]. 施工技术, 2013, 42(9): 1-5. (CHEN Yue. Review on construction technology of tunnel and artificial islands for Hongkong- Zhuhai-Macao Bridge[J]. Construction Technology, 2013, 42(9): 1-5. (in Chinese)) [2] 上海市地震局, 同济大学. 上海市地震动参数区划[M]. 北京: 地震出版社, 2004. (Seismological Bureau of Shanghai City, Tongji University. Ground motion parameter zoning of Shanghai City[M]. Beijing: Seismological Press, 2004. (in Chinese)) [3] 楼梦麟, 邵新刚. 应用通用程序计算深覆盖土层地震反应的几个问题[J]. 振动与冲击, 2015, 34(4): 63-68. (LOU M, SHAO X. Several problems in seismic response calculation of soil layer with deep deposit using general software[J]. Journal of Vibration and Shock, 2015, 34(4): 63-68. (in Chinese)) [4] 董 云. 大型沉管隧道地震行波反应分析[D]. 上海: 同济大学, 2014. (DONG Yun. Seismic response analysis of large-scale immersed tunnel under travelling wave[D]. Shanghai: Tongji University, 2014. (in Chinese)) [5] 张如林. 大型地下结构-土层相互作用体系的地震响应分析[D]. 上海: 同济大学, 2011. (ZHANG Ru-lin. Seismic response analysis of large-scale underground structure-soil interaction system[D]. Shanghai: Tongji University, 2011. (in Chinese)) [6] 楼梦麟, 邵新刚. 土层地震反应显式计算中阻尼矩阵系数的选取[J]. 同济大学学报(自然科学版), 2013, 41(8): 24-30. (LOU Meng-lin, SHAO Xin-gang. Damping matrix coefficient selection in explicit calculation of soil layer seismic response[J]. Journal of Tongji University (Natural Science), 2013, 41(8): 24-30. (in Chinese)) [7] 董 云, 楼梦麟. 基于结构基频确定Rayleigh阻尼系数的优化方法及其讨论[J]. 湖南大学学报(自然科学版), 2014, 42(2): 8-13. (DONG Yun, LOU Meng-lin. An optimization solution for rayleigh damping coefficients based on the fundamental frequency of structure[J]. Journal of Hunan University (Natural Science), 2014, 42(2): 8-13. (in Chinese)) [8] 潘旦光. 地震反应分析中Rayleigh阻尼系数的优化解[J]. 工程力学, 2013, 30(4): 42-46. (PAN Dan-guang. An optimization solution for Rayleigh damping coefficients in seismic response analysis[J]. Engineering Mechanics, 2013, 30(4): 42-46. (in Chinese)) [9] CHOPRA A K. Dynamics of structures: theory and applications to earthquake engineering[M]. New Jersey: Englewood Cliffs, Prentice-Hall, 199.
